Marco ARK-1a Autorefractor & Keratometer
SKU: AR0NKARK1A
The Marco ARK-1a combines autorefraction and keratometry with accommodation testing and retro-illumination. Its Super Luminescent Diode technology and X-Y-Z Eye Tracking system support accurate, repeatable measurements across a wide range of patients.
- Super Luminescent Diode (SLD) for sharper images compared to LED
- Accurate data even through many cataracts
- Eye Tracking system provides X-Y-Z tracking for superior alignment and focus
- Large pupil zone imaging method (up to 6mm diameter)
Technical Details
Marco ARK-1a Autorefractor & Keratometer Specifications
Objective Spherical Refractive Error-30.00 to +25.00 D (VD = 12 mm) (0.01/0.12/0.25 D increments)
Cylindrical Refractive Error0 to ±12.00 D (0.01/0.12/0.25 D increments)
Cylinder Axis0 to 180° (1°/5° increments)
Minimum Measurable Pupil Diameterø2 mm
Corneal Curvature Radius5.00 to 13.00 mm (0.01 mm increments)
Corneal Refractive Power25.96 to 67.50 D (n = 1.3375) (0.01/0.12/0.25 D increments)
Corneal Cylindrical Power0 to ±12.00 D (0.01/0.12/0.25 D increments)
Corneal Cylinder Axis0 to 180° (1°/5° increments)
Pupillary Distance Measurement30 to 85 mm (1 mm increments)
Corneal Size Measurement10.0 to 14.0 mm (0.1 mm increments)
Pupil Size Measurement1.0 to 10.0 mm (0.1 mm increments)
Accommodation Measurement0 to 10.00 D (0.01/0.12/0.25 D increments)
Observation/Display Method6.5-inch color LCD
PrinterThermal line printer with auto cutter
Interface ConnectorsRS-232C: Two ports USB: One port LAN: One port
